Linux Kernel Module Development Guide - A Tutorial for Beginners

Looking to dip your toes into Linux kernel module development? Well, you’re in for a treat! We’ve got a no-frills, step-by-step guide that’ll take you from zero to hero in no time. In this blog, we’ll walk you through setting up your local development environment, using qemu for safe testing, and the optional (but highly recommended) integration of gdb for debugging. Perfect for beginners, this guide will simplify the seemingly complex world of kernel development into an approachable and manageable process. Ready to get started?

Outcome

• stable local development setup
• A qemu VM for safe testing
• A gdb hooked to the test qemu VM for debuging (Optional, strongly advised)

Tools

qemu - “open source machine emulator and virtualizer.” viz.
gdb (optional) - “the GNU Project debugger, allows you to see what is going on inside another program while it executes – or what another program was doing at the moment it crashed.” viz.

Whom

This guide is aimed at newcomers to kernel development. It combines various components into an easy-to-follow workflow for quick and efficient start in kernel development.

This is by no means a definitive guide or a best solution, yet it is one that has served me well.

Technical Notes

File names used in this document are relative. Following the naming conventions provided will ease the referencing process but isn’t mandatory.

Set-up

---

fedora dependencies

sudo dnf group install "Development Tools"

sudo dnf install qemu-kvm qemu-img qemu-system-x86_64 gcc flex bzip2 make ccache bison openssl-devel bc elfutils-libelf-devel

optional: menuconfig for modifying the kernel configuration using gui menu

sudo dnf install ncurses-devel

Qemu VM

The following section is in based on the following qemu fedora guide Non-fedora users should also be able to follow it.

Steps

1. Download a ISO, server flavor(no gui) is probably all you need depending on the module’s purpose
2. Create the following folder structure and move the ISO file accordingly

   ├── cdromimg
   │   └── distro.iso
   └── datadrct


3. Create a raw image for the VM, this is a “virtual” disk

   qemu-img create -f raw datadrct/image.raw 16G


Note: if you use non-minimal system flavor or will be using a lot of disk space, increase the size accordingly.

1. Start the VM and complete the installation. I have chosen the username to be devel which will be used in rest of this tutorial.

qemu-system-x86_64 \
    -boot menu=on \
    -m 2048 \
    -cpu max \
    -smp 4 \
    -cdrom cdromimg/distro.iso> \
    -drive file=datadrct/image.raw,format=raw \
    -accel kvm

Final folder structure

Create a backup of the Image after a completing the system backup including the development tools and all you need before starting the development

├── cdromimg
│   └── distro.iso
└── datadrct
    ├── image.raw
    └── image.raw.backup

Running the VM (Maintenance)

With this you will run in graphics mode unless you add -nographics, You can use it for the VM maintenance.

qemu-system-x86_64 \
    -boot menu=on \
    -m 2048 \
    -cpu max \
    -smp 4 \
    -s  \
    -drive file=datadrct/image.raw,format=raw \
    -accel kvm \
    -net nic \
    -net user,hostfwd=tcp::2323-:22

You will need to run it at leas once to determine the root mount point e.g /dev/sda3. You can do so after running the VM by executing the df command, look for the / symbol in the Mounted on column and write it down.

Running the VM (Development)

VM can access internet
We can SSH to the VM using localhost and a arbitrary port (2323)

qemu-system-x86_64 \
    -m 2048 \
    -cpu max \
    -smp 4 \
    -s \
    -kernel path/to/kernel/arch/x86_64/boot/bzImage \
    -drive file=datadrct/image.raw,format=raw \
    -accel kvm \
    -nographic \
    -append "root=/dev/sda3 nokaslr" \
    -net nic \
    -net user,hostfwd=tcp::2323-:22

• root=/dev/sda3 - specify the root partition based. see previous running option
• Feel free to exclude the -nographic option if you wish to have a separate gui window for the VM.
• -kernel specifies the path to the bzImage

Mount the VM’s image

Don’t do this when the VM is running

sudo mount -t ext4 -o loop,offset=<1234> datadrct/image.raw /mnt/image

-t <filesystem> - depends on your installation
offset=1234 - ofset of the partition that we want to mount

To determine the offset sudo fdisk -l <path/to/image.raw> look for Type: Linxu File

kernel

Get sources

git clone https://git.kernel.org/pub/scm/linux/kernel/git/torvalds/linux.git

If you are developing for specific distro, then seach for the disto’s sources e.g. fedora-ark

configure

kernel config option	value	description
CONFIG_GDB_SCRIPTS	Y	Enables GDB script support for kernel debugging
CONFIG_DEBUG_INFO_REDUCED	N	Keeps full debug information
CONFIG_FRAME_POINTER	Y	Useful for stack traces in debugging

(Optional) Copy existing config and modify it.

cp /boot/config-`uname -r`* .config

run configuration

this will go through configuration options that you need to set. There shouldn’t be any if you have done the previous step ^.

make oldconfig

you can use menuconfig instead of oldconfig to use GUI version

build

make bzImage

make modules

Install

Mount the VM’s image

sudo make modules_install INSTALL_MOD_PATH=/mnt/image

sudo make headers_install INSTALL_HDR_PATH=/mnt/image/usr

sudo make install INSTALL_PATH=/mnt/image/boot

GDB

In the kernel source directory:

make scripts_gdb

add add-auto-load-safe-path /path/to/linux-build to ~/.gdbinit

Development

---

_This guide doesn’t covert the actual module developement as there are enough reources on this toppic https://www.thegeekstuff.com/2013/07/write-linux-kernel-module/

Rebuilding the kernel

If you modify the module files only then perform the following:

make modules M=/path/to/module.ko

If you modify something outside of the module itself (e.g. some files in include, something in the kernel core..) then rebuild the kernel again

Provide the build to the VM system

The following will copy the module to the user’s home directory.

scp -P 2323 path/to/module.ko devel@localhost:

Load the kernel module inside the VM

sudo insmod path/to/module.ko

alternatively you can use modprobe but be sure that you have copied the kernel to the right directory i.e. /lib/modules/...

debug the kernel

Run gdb on in the kernel sources (Not in the VM)

gdb vmlinux

Connect gdb to VM

target remote :1234

The system freezes upon connecting. Use continue to resume.

Feel free to interrupt at any moment to enter gdb commands by pressing CTRL+C

Load the modules before the next step

load kernel and module symbols

lx-symbols

continue as normal…

Things to watch out for

• Avoid running the VM when the image.raw is mounted.
• Incrementally test your setup.
• Use version control like Git for your development.

Scriptlets

scripts you might find useful

Mount the image, kill the running VM if needed

ps -a | grep qemu && pkill qemu
sudo mount -t ext4 -o loop,offset=8592031744 datadrct/image.raw /mnt/image

Automatically unmounted the image before running the VM

sudo umount /mnt/image/
qemu-system-x86_64 -boot menu=on -m 2048 -cpu max...

Reload module in VM

lsmod | grep module > /dev/null && sudo rmmod --force module
sudo insmod ~/module.ko && lsmod | grep module

replace module with the name of your module

Other development notes

Working on VM

You can use Tmux (viz.) on a local machine as well as the VM for testing. You are encouraged to try it even if you aren’t familiar with it.

Attaching remote (VM) Tmux session

First you have to create a Tmux session on the VM you would do so by running it at the system startup (adding tmux to startup script).

Then you attach from the local machine to the VM using:

ssh -p 2323 devel@localhost -t tmux attach-session

---
